Please ask a marketing department/department of technical service.

An ASTEC Co., Ltd. Sales department / Technical service division

TEL: 042-651-9411　FAX: 042-651-7423

CDM-30A/40A
CDH-3A
CDH-5A
CDH-2A
CDH-3ANC
CDH-2AM
CDH-3AM
CDH-2AMS
A34CNC/AEC32
A34CNC2S
A34CNC2/AEC32
A66CNC/AEC32
A66CNC3/AEC2/AGC2
A34CNC3S
A34CNC3/AEC2/AGC2

CDM-30A/40A

CDM-30A
CDM-40A

	Unit	CDM-30A	CDM-40A
Work-table dimension (width × depth)	mm	600×300	700×400
Work tank inside dimension (width × depth × height)	mm	850×470×350	1000×600×450
Distance from the table top to the electrode clamp face	mm	280-480	315-515
Table moving distance (Forword and Back × Right and L eft)	mm	300×200	400×300
Maximum Load weight of the work	kgf	500	700
The electrode maximum suspension weight	kgf	25	50
Ram up-and-down moving distance	mm	200
Digital-display minimum unit (X, Y, Z-axis)	μm	5
Machine body weight	kgf	1000	2000
Processing-liquid tank capacity	ℓ	200	380
Filtration system		Paper filter 1
Processing-liquid tank input	KVA	0.75	1.5
Processing-liquid tank weight	Kgf	170	205
The maximum processing averge current value	A	30	40
The processing power-source maximum input	KVA	4.5	5.0
The minimum electrode consumption ratio	%	1.0 or less
Processing power-source dimension (width × depth × height)	mm	620×730×1630
Processing power-source weight	kgf	200

CDH-3A

	Unit	CDH-3A
Work-table dimension (width × depth)	mm	500×360
Work tank inside dimension (width × depth)	mm	820×550
Distance from the table top to the electrode clamp face	mm	220
Table moving distance (Forword and Back x Right and L eft)	mm	300×200
Maximum Load weight of the work	kgf	300
The diameter of the electrode	mm	ø0.3-3.0
Servo feed distance	mm	250
Processing head up-and-down distance	mm	200
Machine body weight	kgf	900
Processing-liquid tank capacity	ℓ	20
The maximum processing averge current value	A	40
The maximum input	KVA	4.5

To the head of this page

CDH-5A

	Unit	CDH-5A
Work-table dimension (width × depth)	mm	660×560
Work tank inside dimension (width × depth)	mm	840×780
Distance from the table top to the electrode clamp face	mm	220
Table moving distance (Forword and Back x Right and L eft)	mm	500×400
Maximum Load weight of the work	kg	200
The diameter of the electrode	mm	ø0.3-3.0
Z-axis Servo system		D.C. servo system
Ram up-and-down moving distance (Z-axis)	mm	250
Z-axis Column moving distance	mm	200
The minimum digital display unit	mm	X Y-axis 0.005
XY axis quick moving mechanism (motor drive)	Mm/min	X320, Y410 (No loading object)
Machine body weight	kg	1,200
The maximum processing averge current value	A	40
Current wave-height change	Stage	1-9
Pulse width change	μsec	3-99
Pouse time change	μsec	5-99
The maximum input	KVA	4.5
Input power		3 phase AC200.220V 50-60Hz
Input power		Pure-water, tap water, and tap water + water soluble processing liquid
Processing-liquid tank capacity	ℓ	20

CDH-2A

	Unit	CDH-2A
Work-table dimension (width × depth)	mm	260×314
Work tank inside dimension (width × depth)	mm	368×463
Work-table height	mm	54.5
Work maximum height	mm	240
Table moving distance (width × depth)	mm	180×200
Maximum Load weight of the work	kgf	100
The diameter of the electrode	mm	ø0.2-3.0
Servo feed distance	mm	300
Processing head up-and-down distance	mm	245
Processing-liquid tank capacity	ℓ	20
The maximum processing averge current value	A	30
The maximum input	KVA	3.5

To the head of this page

CDH-3ANC

	Unit	CDH-3ANC
Work-table dimension (width × depth)	mm	500×360
Work tank inside dimension (width × depth)	mm	820×550
The minimum digital display unit	mm	X Y-axis 0.001　Z-axis0.01
Table moving distance (width × depth)	mm	300×200
Maximum Load weight of the work	kgf	100
Servo feed distance	mm	250
Processing head up-and-down distance	mm	200
The diameter of the electrode	mm	0.3-3.0
Maximum electrode length	mm	Minimum200　Maximum400
The maximum processing averge current value	A	40

CDH-2AM

	Unit	CDH-2AM
Work-table dimension (width × depth)	mm	260×314
Work tank inside dimension (width × depth)	mm	368×463
Work-table height	mm	54.5
Table moving distance (X-axis × Y-axis)	mm	200×200
Maximum Load weight of the work	kgf	100
Work maximum height	mm	225
The diameter of the electrode	mm	ø0.2-3.0
Z-axis servo feed distance	mm	400
Z-axis processing head up-and-down distance	mm	245
Z-axis Servo system		DC servo system (DC serve)
Electrode rotaition device		DC motor
Processing-liquid tank capacity	ℓ	20
The maximum processing averge current value	A	30
The maximum input	KVA	3.5

To the head of this page

CDH-3AM

	Unit	CDH-3AM
Work-table dimension (width × depth)	mm	400×400
Work tank inside dimension (width × depth)	mm	553×647
Work-table height	mm	64
Table moving distance (X-axis × Y-axis)	mm	300×300
Maximum Load weight of the work	kgf	300kgf
Work maximum height	mm	300
The diameter of the electrode	mm	φ0.2-3.0
Z-axis servo feed distance	mm	400
Z-axis processing head up-and-down distance	mm	300
Z-axis Servo system		DC servo system (DC serve)
Electrode rotaition device		DC motor
Processing-liquid tank capacity	ℓ	20
The maximum processing averge current value	A	40
The maximum input	KVA	4.5

CDH-2AMS

CDH-2AMS Unit type for automatic machines
CDH-2AMS Double head

	Unit	CDH-2AM
Z-axis servo feed distance	mm	400
The diameter of the electrode	mm	300
The maximum input	KVA	3.5
Processing conditions	Step	IP (switching)　1-8
Function preselection capability	μsec	Ton (switching)　1-99
Function preselection capability	μsec	Toff (switching)　1-99

To the head of this page

A34CNC/AEC32

	Unit	A34CNC
Work-table dimension (width × depth × height)	mm	400×490×64
Work tank inside dimension (width × depth)	mm	556×740
Table moving distance (X-axis × Y-axis)	mm	300×400
W-axis processing head up-and-down distance	mm	300
Z-axis servo feed distance	mm	340
The diameter of the electrode	mm	ø0.2-3.0
Processing-liquid tank capacity	ℓ	20
Maximum Load weight of the work	kgf	300
Machine body dimension (width × depth × height)	mm	1,450×1,250×1,910
Machine body weight	kgf	1,000
Machine installation dimension	mm	1,950×1,750
The maximum processing averge current value	A	40
The maximum input	KVA	4.5
Input power	VAC, Hz	200/220, 3-Phase, 50/60
Processing conditions	A step	IP(switching)2- 57 and 23
Function preselection capability		Ton(switching)1-999
Function preselection capability		Toff(switching)1-999
Capacitor	Step	0-9.10

A34CNC2S

	Unit	A34CNC2S
Work-table dimension (width × depth × height)	mm	400×490×64
Work tank inside dimension (width × depth)	mm	556×790
Table moving distance (X-axis × Y-axis)	mm	300×400
W-axis processing head up-and-down distance	mm	300
Z-axis servo feed distance	mm	340
The diameter of the electrode	mm	ø0.2-4.0
Processing-liquid tank capacity	ℓ	20
Maximum Load weight of the work	kgf	300
Machine body dimension (width × depth × height)	mm	1,450×1,279×2,017
Machine body weight	kgf	700
Machine installation dimension	mm	2,300×2,000

To the head of this page

A34CNC2/AEC32

	Unit	A34CNC2 / AEC32
Work-table dimension (width × depth × height)	mm	400×490×64
Work tank inside dimension (width × depth)	mm	556×790
Table moving distance (X-axis × Y-axis)	mm	300×400
W-axis processing head up-and-down distance	mm	300
Z-axis servo feed distance	mm	340
The diameter of the electrode	mm	ø0.2-3.0
Processing-liquid tank capacity	ℓ	20
Maximum Load weight of the work	kgf	300
Machine body dimension (width × depth × height)	mm
Machine body weight	kgf	1000
Machine installation dimension	mm	2,900×2,000

A66CNC/AEC32

	Unit	A66CNC / AEC32
Work-table dimension (width × depth × height)	mm	ø40×65
Work tank inside dimension (width × depth)	mm	843×977
Table moving distance (X-axis × Y-axis)	mm	650×650
W-axis processing head up-and-down distance	mm	500
Z-axis servo feed distance	mm	660
The diameter of the electrode	mm	ø0.2-3.0
Processing-liquid tank capacity	ℓ	WR-50A
Maximum Load weight of the work	kgf	500
Machine body dimension (width × depth × height)	mm	1,770×2,250×2,850
Machine body weight	kgf	2700
Machine installation dimension (width × depth)	mm	3,000×3,000

A66CNC3/AEC2/AGC2

	Unit	A66CNC3/AEC2/AGC2
Work-table dimension (width × depth × height)	mm	ø40×65
Work tank inside dimension (width × depth)	mm	843×977
Table moving distance (X-axis × Y-axis)	mm	650×650
W-axis processing head up-and-down distance	mm	500
Z-axis servo feed distance	mm	660
The diameter of the electrode	mm	ø0.3-3.0
Processing-liquid tank capacity	ℓ	20
Maximum Load weight of the work	kgf	500
Machine body dimension (width × depth × height)	mm	1,770×1,885×2,850
Machine body weight	kgf	2500
Machine installation dimension (width × depth)	mm	3,000×3,000

A34CNC3S

	Unit	A34CNC3S
Work-table dimension (width × depth × height)	mm	400×490×64
Work tank inside dimension (width × depth)	mm	556×790
Table moving distance (X-axis × Y-axis)	mm	300×400
W-axis processing head up-and-down distance	mm	300
Z-axis servo feed distance	mm	340
The diameter of the electrode	mm	ø0.2-4.0
Processing-liquid tank capacity	ℓ	20
Maximum Load weight of the work	kgf	300
Machine body dimension (width × depth × height)	mm	1,027×1,307×2,526
Machine body weight	kgf	1000
Machine installation dimension (width × depth)	mm	2,300×2,000

A34CNC3/AEC2/AGC2

	Unit	A34CNC3/AEC2/AGC2
Work-table dimension (width × depth × height)	mm	400×490×64
Work tank inside dimension (width × depth)	mm	556×790
Table moving distance (X-axis × Y-axis)	mm	300×400
W-axis processing head up-and-down distance	mm	300
Z-axis servo feed distance	mm	340
The diameter of the electrode	mm	ø0.3-3.0
Processing-liquid tank capacity	ℓ	20
Maximum Load weight of the work	kgf	300
Machine body dimension (width × depth × height)	mm	1,446×1,307×2,526
Machine body weight	kgf	1200
Machine installation dimension (width × depth)	mm	2,900×2,000
